Author: Radomskyi Maksym VasyliovychThe most vulnerable items in any car are the elements of electric circuits. One of such blocks are lamps in the car. Therefore, in order to avoid unpleasant situations, it is recommended to have a set of different types of bulbs: main beam or dipped beam, dimensions and turn signals, as well as light rooms.
The values and purpose of the lamps
The purpose of the lamps | The value of lamps |
Dazzle | 12V/55W (H1) |
Distant light | 12 V/55 W (H1) |
Parking light | 12 V/4 W |
Fog light | 12 V 55 W (H3) |
Direction indicators (front lamps yellow) | 12 V/21 W |
Brake/tail lamp | 12V/21/5W |
It is also worth noting that if a car has xenon bulbs, replace them yourself it is impossible in any case. The replacement lamp is only at enterprise Audi. For the safety of these lamps can not be opened as indicated in the table below.
How to replace the dipped beam
Instruction:
- open the hood of the car;
- bracket cap aside and remove the cap;
- remove the old lamp and fit a new one, so that both tabs of the lamp clip into the hole;
- to return the bracket to its place and pressed;
- connect the tip wire;
- back to mount hood so that all the protrusions included in the corresponding slots;
- press the bracket;
- to adjust the level of light.
Thus, you can easily change the dipped beam in an unpredictable situation. In addition, if you need tuning Audi, you can browse our catalogue on the website and choose not only high quality lighting, and many other original ideas.
